BASE – Bsmart

Supported devices list

Supported protocols: JTAG, SPI, QSPI, SWD, BDM, CSI, I2C, C2I, MDI, ICSP, EICSP, UART, USART.

Manufacturer	Device_Code	Family	Protocols	Driver	Memory_Size	Group
Intel	10M02DC	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1
Intel	10M02DCU324	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1
Intel	10M02DCV36	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1
Intel	10M02SC	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1
Intel	10M02SCE144	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1
Intel	10M02SCM153	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1
Intel	10M02SCU169	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1
Intel	10M02SCU324	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1
Intel	10M04DA	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1
Intel	10M04DAF256	MAX_10	JTAG	CPLD	CONF_MEM: 256 MB	1

small form factor to foster portability and easy handling;
- 128 mm x 70 mm x 18 mm without battery pack
supplied through a 15V power adapter (not included);
isolated Ethernet LAN 10/100/1000 wired communication interface;
isolated USB-UART wired communication interface;
highly configurable Digital Input Output (DIOs) lines to support interfacing to microprocessors and serial memories (up to 8 Digital Input Output lines);
Digital Input Output signals frequency up to 75MHz;
DIOs programmable voltage (VPROG0) and additional programmable voltage (VPROG1) provided to the target device:
- VPROG0 voltage range 1.2V – 5.5V @ 1A max
- VPROG1 voltage range 3.3V – 12.0V @ 1A max
continuous monitoring of output power rail voltages and currents;
Intel SOC FPGA with 800MHz ARM Cortex-A9 Hard Processor System;
512 MB on-board RAM DDR3 dynamic memory;
Micro SD Card reader with up to 256 GB static memory;
On-board timekeeper and calendar for time-stamped log file.
